Revised 02.19.10 www.AIS-INC.com 37
AIS DiVi Installation Instructions (P-DVINSTRUCT01)
Hold shelf pan between shelf
ends and lower over nuts on
shelf end. This may require
turning nuts out to loosen
slightly. BE CAREFUL NOT
TO SCRATCH paint on shelf
ends as you insert and lower
shelf.
Shelf pan has two slot patterns
on end. Use slot pattern as
show to properly position shelf.
Tighten nuts on shelf studs.
Lock slot should be positioned
at front on bottom shelf pan.
