Revised 02.19.10 www.AIS-INC.com 46
AIS DiVi Installation Instructions (P-DVINSTRUCT01)
Install flatplates at seams
between worksurfaces in front
of shared cantilevers.
Align pedestal flush with front
of worksurface and screw to
worksurface with screws
labeled “For worksurfaces”.
Use at least 2 screws at the
front of pedestal. For best
results, use screws at all 4
corners of pedestal.
To replace drawers, push all
ball bearing slides into
pedestal BUT KEEP INNER
BALL BEARING CARRIAGE
pulled forward to front of slide.
Carefully align track on drawer
boxes with inner slide carriage
and slowly insert drawer...
