3433
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
MECHANICAL PARTS LIST 1/1
1 8A-CDA-006-010 WINDOW,CASS
<110HRJ(S),100K(S),99K(S),100EZ(S),170U(S),170K(S),170HA(S)>
1 8A-CDA-062-010 WINDOW,CASS D
<100HE(S),110EZ(S),100HRJ(S)>
1 8A-CDA-072-010 WINDOW,CASS EZ L<100EZ(L)>
1 8A-CDA-096-010 WINDOW,CASS EZ P<100EZ(P)>
1 8A-CDA-128-010 WINDOW,CASS L<110EZ(L)>
2 87-B00-010-010 BADGE,AIWA 30.5-5.2 S 2.5L
3 8A-CDA-003-010 LID,CASS
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
3 8A-CDA-069-010 LID,CASS EZ L<100EZ(L)>
3 8A-CDA-093-010 LID,CASS EZ P<100EZ(P)>
3 8A-CDA-125-010 LID,CASS L<110EZ(L)>
4 8A-CDA-212-010 SPR-T,CASS
5 8A-CDL-031-010 WINDOW,LED<170K(S),170HA(S)>
5 8A-CDA-008-010 WINDOW,LED<100EZ(L)>
5 8A-CDA-039-010 WINDOW,LED LH
<110HRJ(S),110EZ(S),110EZ(L)>
5 8A-CDA-113-010 WINDOW,LED LOW EZ P<100EZ(P)>
5 8A-CDA-042-010 WINDOW,LED LOW LH
<100HE(S),100K(S),99K(S),100EZ(S),100HRJ(S)>
5 8A-CDL-033-010 WINDOW,LED U<170U(S)>
6 8A-CDA-028-010 CABI ASSY,FRONT
<110HRJ(S),170U(S),170HA(S)>
6 8A-CDA-120-010 CABI ASSY,FRONT A99<99K(S)>
6 8A-CDA-034-010 CABI ASSY,FRONT EZ
<110EZ(S),170K(S)>
6 8A-CDA-122-010 CABI ASSY,FRONT EZ L<110EZ(L)>
6 8A-CDA-036-010 CABI ASSY,FRONT LOW EZ
<100K(S),100EZ(S)>
6 8A-CDA-066-010 CABI ASSY,FRONT LOW EZ L
<100EZ(L)>
6 8A-CDA-090-010 CABI ASSY,FRONT LOW EZ P
<100EZ(P)>
6 8A-CDA-054-010 CABI ASSY,FRONT LOW HR
<100HE(S),100HRJ(S)>
7 8A-CDA-206-010 HLDR,SPKR
8 8A-CDA-020-010 KNOB,SL BAND
<110HRJ(S),100HE(S),100HRJ(S),170U(S),170HA(S)>
8 8A-CDA-059-010 KNOB,SL BAND EZ
<100K(S),110EZ(S),99K(S),100EZ(S),170K(S)>
8 8A-CDA-081-010 KNOB,SL BAND EZ L<100EZ(L)>
8 8A-CDA-105-010 KNOB,SL BAND EZ P<100EZ(P)>
8 8A-CDA-136-010 KNOB,SL BAND L<110EZ(L)>
9 8A-CDA-009-010 WINDOW,TU<170U(S)>
9 8A-CDA-045-010 WINDOW,TU EZ
<100K(S),110EZ(S),99K(S),100EZ(S),170K(S)>
9 8A-CDA-073-010 WINDOW,TU EZ L<100EZ(L)>
9 8A-CDA-097-010 WINDOW,TU EZ P<100EZ(P)>
9 8A-CDA-046-010 WINDOW,TU HR
<110HRJ(S),100HE(S),100HRJ(S),170HA(S)>
9 8A-CDA-129-010 WINDOW,TU L<110EZ(L)>
10 8A-CDA-007-010 LENS,LED
11 8A-CDA-019-010 KEY,VOL
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
11 8A-CDA-080-010 KEY,VOL EZ L<100EZ(L)>
11 8A-CDA-104-010 KEY,VOL EZ P<100EZ(P)>
11 8A-CDA-135-010 KEY,VOL L<110EZ(L)>
12 8A-CDA-004-010 LID,CD
<110HRJ(S),100K(S),99K(S),100EZ(S),170U(S),170K(S),170HA(S)>
12 8A-CDA-061-010 LID,CD D
<100HE(S),110EZ(S),100HRJ(S)>
12 8A-CDA-070-010 LID,CD EZ L<100EZ(L)>
12 8A-CDA-094-010 LID,CD EZ P<100EZ(P)>
12 8A-CDA-126-010 LID,CD L<110EZ(L)>
13 8A-CDA-213-010 COVER, CHUCK
14 87-036-368-010 MAGNET
15 8A-CDA-207-010 HLDR,CHUCK
16 8A-CDA-150-010 BASE,CHUCK F/M
17 88-CD9-211-210 RING,CHUCK
18 8A-CDA-620-010 FF-CABLE,16P FR-MAIN
19 8A-CDA-208-110 HLDR,LED
20 8A-CDA-622-010 FF-CABLE,8P CD-FR
21 8A-CDA-016-010 KEY,CD
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
21 8A-CDA-078-010 KEY,CD EZ L
<100EZ(P),100EZ(L),110EZ(L)>
22 87-063-165-010 OIL-DMPR 150
23 8A-CDA-017-010 KEY,MODE
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
23 8A-CDA-079-010 KEY,MODE EZ L
<100EZ(P),100EZ(L),110EZ(L)>
24 88-CH6-220-010 CUSHION,CD A
25 8A-CDA-621-010 FF-CABLE,16P CD-RF
26 8A-CDA-012-010 CHAS,CD<EXCEPT 100EZ(P),100EZ(L)>
26 8A-CDA-180-010 CHAS,CD EZ L<100EZ(L)>
26 8A-CDA-114-010 CHAS,CD EZ P<100EZ(P)>
27 87-036-389-010 SW,PUSH LOCK
28 8A-CDA-211-010 SPR-T,CD
29 8A-CDA-010-110 HANDL,ARM
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
29 8A-CDA-074-010 HANDL,ARM EZ L<100EZ(L)>
29 8A-CDA-098-010 HANDL,ARM EZ P<100EZ(P)>
29 8A-CDA-130-010 HANDL,ARM L<110EZ(L)>
30 8A-CDA-011-010 HANDL,COVER
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
30 8A-CDA-075-010 HANDL,COVER EZ L<100EZ(L)>
30 8A-CDA-099-010 HANDL,COVER EZ P<100EZ(P)>
30 8A-CDA-131-010 HANDL,COVER L<110EZ(L)>
31 87-NF8-220-010 DMPR,150
32 8Z-CH4-640-010 ANT,ROD
33 8Z-CDB-169-010 PANEL,CD SANYO
34 8A-CDA-027-010 KEY,PAUSE
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
34 8A-CDA-088-010 KEY,PAUSE EZ L<100EZ(L)>
34 8A-CDA-112-010 KEY,PAUSE EZ P<100EZ(P)>
34 8A-CDA-143-010 KEY,PAUSE L<110EZ(L)>
35 8A-CDA-026-010 KEY,STOP
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
35 8A-CDA-087-010 KEY,STOP EZ L<100EZ(L)>
35 8A-CDA-111-010 KEY,STOP EZ P<100EZ(P)>
35 8A-CDA-142-010 KEY,STOP L<110EZ(L)>
36 8A-CDA-025-010 KEY,FF
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
36 8A-CDA-085-010 KEY,FF EZ L<100EZ(L)>
36 8A-CDA-109-010 KEY,FF EZ P<100EZ(P)>
36 8A-CDA-140-010 KEY,FF L<110EZ(L)>
37 8A-CDA-024-010 KEY,REW
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
37 8A-CDA-086-010 KEY,REW EZ L<100EZ(L)>
37 8A-CDA-110-010 KEY,REW EZ P<100EZ(P)>
37 8A-CDA-141-010 KEY,REW L<110EZ(L)>
38 8A-CDA-023-010 KEY,PLAY
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
38 8A-CDA-084-010 KEY,PLAY EZ L<100EZ(L)>
38 8A-CDA-108-010 KEY,PLAY EZ P<100EZ(P)>
38 8A-CDA-139-010 KEY,PLAY L<110EZ(L)>
39 8A-CDA-022-010 KEY,REC
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
39 8A-CDA-083-010 KEY,REC EZ L<100EZ(L)>
39 8A-CDA-107-010 KEY,REC EZ P<100EZ(P)>
39 8A-CDA-138-010 KEY,REC L<110EZ(L)>
40 8A-CDA-221-010 SPR-P,REC<EXCEPT 100HE(S)>
41 8A-CDA-220-010 PLATE,REC
42 8A-CDA-021-010 KNOB,RTRY TU
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
42 8A-CDA-082-010 KNOB,RTRY TU EZ L<100EZ(L)>
42 8A-CDA-106-010 KNOB,RTRY TU EZ P<100EZ(P)>
42 8A-CDA-137-010 KNOB,RTRY TU L<110EZ(L)>
43 8A-CDA-013-010 POINTER,TU
44 8A-CDA-201-010 HLDR,TU
45 8A-CDA-216-010 GEAR,TU B
46 8A-CDA-203-010 GUIDE,GEAR
47 8A-CDA-202-010 GEAR,RELAY
48 8A-CDA-215-010 DRUM,TU
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange
COLOR NAME TABLE
49 8A-CDL-002-010 CABI,REAR<170U(S),170K(S)>
49 8A-CDA-002-010 CABI,REAR<110EZ(S)>
49 8A-CDA-118-010 CABI,REAR A99<99K(S)>
49 8A-CDA-124-010 CABI,REAR EZ L<110EZ(L)>
49 8A-CDA-030-010 CABI,REAR LH<110HRJ(S)>
49 8A-CDL-030-010 CABI,REAR LH<170HA(S)>
49 8A-CDA-037-010 CABI,REAR LOW<100K(S),100EZ(S)>
49 8A-CDA-068-010 CABI,REAR LOW EZ L<100EZ(L)>
49 8A-CDA-092-010 CABI,REAR LOW EZ P
<100EZ(P)>
49 8A-CDA-038-010 CABI,REAR LOW LH
<100HE(S),100HRJ(S)>
50 8A-CDA-005-010 LID,BATT
<EXCEPT 100EZ(P),100EZ(L),110EZ(L)>
50 8A-CDA-071-010 LID,BATT EZ L<100EZ(L)>
50 8A-CDA-095-010 LID,BATT EZ P<100EZ(P)>
50 8A-CDA-127-010 LID,BATT L<110EZ(L)>
51 8Z-CD5-634-010 COVER,AC SOCKET
52 8A-CDA-626-010 CONN ASSY,2P DOOR
53 8A-CDA-630-010 CONN ASSY,4P RPH
54 8A-CDA-633-010 CONN ASSY,4P SP
55 8A-CDA-631-010 CONN ASSY,4P TA-ME
!
57 87-A60-178-010 JACK,AC E W/SW<EXCEPT 170U(S)>
!
57 87-A60-177-010 JACK,AC U W/SW<170U(S)>
58 8A-CDA-018-010 KEY,QSOUND
<110HRJ(S),110EZ(S),170U(S),170K(S),170HA(S)>
58 8A-CDA-134-010 KEY,QSOUND L<110EZ(L)>
59 8A-CDA-612-010 PT,E 2.5W
<EXCEPT 110HRJ(S),100HE(S),100HRJ(S),170U(S),170HA(S)>
59 8A-CDA-613-010 PT,H 2.5W
<110HRJ(S),100HE(S),100HRJ(S),170HA(S)>
!
59 8A-CDA-611-010 PT,U 2.5W<170U(S)>
60 8A-CH4-682-010 SPKR,10- 7OHM
61 88-CD6-661-010 HLDR,BAR ANT.
62 87-A91-369-010 SW,AC SL 2 2 2 SDKGA41700
<110HRJ(S),100HE(S),100HRJ(S),170HA(S)>
A 87-721-096-410 QT2+3-10 GLD
B 87-751-104-410 VT2+3-30
C 8A-CK4-223-010 S-SCREW,CD
D 87-067-566-010 TAPPING SCREW, VFTT+3-6
E 87-352-075-210 VT2+2.6-10
F 8A-CDA-222-010 S-SCREW,CASS+2.6-4
H 87-253-097-410 U+3-12 BLK
I 87-261-073-410 V+2.6-6
J 87-751-096-410 VT2+3-10 GLD
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
