! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-14-

ELECTRICAL PARTS LIST - 9/12 (CSD-FD79/77) - 9/10

CSD-FD77 CSD-FD79

CSTC USTC

TUNER O C 0066 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b

TUNER O C 0067 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b

TUNER O C 0068 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b

TUNER O C 0069 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b

TUNER O CF 0002 87-A91-729-110 FLTR,SFE10.7 MS2C20-A a b

TUNER O CF 0003 87-A91-730-110 FLTR,CDA10.7 MG77A-A a b

TUNER O CF 0010 87-A91-728-110 FLTR,KIT KMFC5184-A a b

TUNER O CN 0001 87-A60-621-010 CONN,4P V 2MM JMT a b

TUNER O CN 0002 87-A60-624-010 CONN,7P V 2MM JMT a b

TUNER X CN 0003 8Z-CT4-623-010 PIN,TESTDIA0.9-10 a b

TUNER X CN 0004 8Z-CT4-623-010 PIN,TESTDIA0.9-10 a b

TUNER X CN 0005 8Z-CT4-623-010 PIN,TESTDIA0.9-10 a b

TUNER X CN 0006 8Z-CT4-623-010 PIN,TESTDIA0.9-10 a b

TUNER X CN 0007 8Z-CT4-623-010 PIN,TESTDIA0.9-10 a b

TUNER O D 0001 87-A41-143-040 C-VARI-CAP,SVC383 a b

TUNER O D 0002 87-A40-916-040 C-VARI-CAP,HVC202A a b

TUNER O D 0003 87-A40-916-040 C-VARI-CAP,HVC202A a b

TUNER S D 0004 87-070-345-080 DIODE,1N4148 a b

TUNER S D 0005 87-070-345-080 DIODE,1N4148 a b

TUNER S IC 0001 87-A20-851-040 C-IC,TA2111F a b

CSD-FD77 CSD-FD79

CSTC USTC

TUNER S IC 0002 87-A21-928-010 IC,LC72131D-N a b

TUNER X JR 0001 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0002 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0003 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0004 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0005 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0006 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0007 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0008 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0009 88-108-000-080 C-JUMPER,U a .

TUNER X JR 0010 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0011 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0012 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0013 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0014 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0015 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0016 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0017 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0018 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0019 88-108-000-080 C-JUMPER,U a b

CSD-FD77 CSD-FD79

CSTC USTC

TUNER X JR 0020 88-108-000-080 C-JUMPER,U a b

TUNER X JR 0021 88-108-000-080 C-JUMPER,U a .

TUNER O L 0001 87-A50-420-010 COIL,MW OSC(SYN) a b

TUNER O L 0002 87-A50-772-010 COIL,FM RF EX(CCH) a b

TUNER O L 0003 8A-CH4-670-010 BAR-ANT,MW 2B-ACH(COI) a b

TUNER X L 0004 88-100-000-010 PLATING-JW, 0.58 SN95 a b

TUNER O L 0005 87-A50-560-010 COIL,FM BPF(ACD) a b

TUNER O L 0006 87-A91-308-010 FLTR,PCFAZH- 450T (TOK) a b

TUNER O L 0007 87-005-849-080 COIL,10UH K CECS a b

TUNER O L 0008 87-A50-770-010 COIL,FM OSC(CCH) a b

TUNER S Q 0001 87-A30-288-040 C-TR,DTC114YKA a b

TUNER S Q 0002 87-026-447-080 TR,2SC1740SR a b

TUNER S Q 0003 89-111-624-080 C-TR,2SA1162Y a b

TUNER S Q 0004 87-A30-283-040 C-TR,DTA114YKA a b

TUNER S Q 0005 87-A30-076-080 C-TR,2SC3052F a b

TUNER S Q 0006 87-A30-076-080 C-TR,2SC3052F a b

TUNER S Q 0007 89-327-143-080 C-TR,2SC2714O a b

TUNER S Q 0008 89-327-143-080 C-TR,2SC2714O a b

TUNER S Q 0009 87-A30-283-040 C-TR,DTA114YKA a b

TUNER S Q 0010 87-A30-283-040 C-TR,DTA114YKA a b

CSD-FD77 CSD-FD79

CSTC USTC

TUNER S Q 0011 87-A30-287-040 C-TR,DTC114TKA a b

TUNER O R 0001 88-108-102-080 C-RES,U 1K-1/16W J a b

TUNER X R 0002 88-108-104-080 C-RES,U 100K-1/16W J a b

TUNER X R 0003 88-108-330-080 C-RES,U 33-1/16W J a b

TUNER O R 0004 88-108-102-080 C-RES,U 1K-1/16W J a b

TUNER O R 0005 88-108-473-080 C-RES,U 47K-1/16W J a b

TUNER X R 0006 88-108-100-080 C-RES,U 10-1/16W J a b

TUNER X R 0007 88-108-472-080 C-RES,U 4.7K-1/16W J a b

TUNER X R 0008 88-108-100-080 C-RES,U 10-1/16W J a .

TUNER X R 0008 88-108-150-080 C-RES,U 15-1/16W J . b

TUNER X R 0009 88-108-221-080 C-RES,U 220-1/16W J a b

TUNER X R 0010 88-108-221-080 C-RES,U 220-1/16W J a b

TUNER O R 0011 88-108-223-080 C-RES,U 22K-1/16W J a b

TUNER O R 0012 88-108-102-080 C-RES,U 1K-1/16W J a b

TUNER X R 0013 88-108-472-080 C-RES,U 4.7K-1/16W J a b

TUNER X R 0014 88-108-104-080 C-RES,U 100K-1/16W J a b

TUNER X R 0015 88-108-221-080 C-RES,U 220-1/16W J a b

TUNER O R 0016 88-108-473-080 C-RES,U 47K-1/16W J a b

TUNER X R 0017 88-108-222-080 C-RES,U 2.2K-1/16W J a b

TUNER X R 0018 88-108-222-080 C-RES,U 2.2K-1/16W J a b
