! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-15-
ELECTRICAL PARTS LIST - 10/12 (CSD-FD79/77) - 10/10
CSD-FD77 CSD-FD79
CSTC USTC
TUNER X R 0019 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0020 88-108-000-080 C-JUMPER,U a b
TUNER X R 0021 88-108-331-080 C-RES,U 330-1/16W J a b
TUNER X R 0022 88-108-104-080 C-RES,U 100K-1/16W J a b
TUNER X R 0023 88-108-104-080 C-RES,U 100K-1/16W J a b
TUNER O R 0024 88-108-473-080 C-RES,U 47K-1/16W J a b
TUNER X R 0025 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0026 88-121-472-080 RES,4.7K-1/8W J a b
TUNER X R 0028 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0029 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0030 88-108-271-080 C-RES,U 270-1/16W J a b
TUNER X R 0031 88-108-121-080 C-RES,U 120-1/16W J a b
TUNER O R 0032 88-108-562-080 C-RES,U 5.6K-1/16W J a b
TUNER O R 0033 88-108-102-080 C-RES,U 1K-1/16W J a b
TUNER X R 0034 88-108-681-080 C-RES,U 680-1/16W J a b
TUNER X R 0036 88-121-104-080 RES,100K-1/8W J a b
TUNER X R 0037 88-108-104-080 C-RES,U 100K-1/16W J a b
TUNER X R 0041 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0042 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0043 88-108-472-080 C-RES,U 4.7K-1/16W J a b
CSD-FD77 CSD-FD79
CSTC USTC
TUNER X R 0044 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0045 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0046 88-108-472-080 C-RES,U 4.7K-1/16W J a b
TUNER X R 0047 88-108-222-080 C-RES,U 2.2K-1/16W J a b
TUNER X R 0049 88-108-000-080 C-JUMPER,U a b
TUNER O R 0050 88-108-332-080 C-RES,U 3.3K-1/16W J a b
TUNER X SH 0001 88-ZA1-605-010 SHLD-CASE,IFT CAP-CASE . b
TUNER O TC 0001 87-011-254-080 TRIMMER,CER 20P 4.0X4.5 ECR a b
TUNER O X 0001 87-A70-306-010 VIB,XTAL 4.500MHZ CSA-309ST a b
