AJA ADA4 4-Ch Bi-directional Audio A/D and D/A Converter User Manual — Specifications
Specifications
Item Specification
Analog Audio I/O Balanced, XLR. One Channel per XLR connector.
AES Audio I/O Balanced 110 ohm, XLR. Two Channels per XLR
connector.
Analog Audio Levels (with Respect
to Full Scale Digital)
+24dBu (SMPTE RP155), +18dBu (EBU R68),
+15dBu (Germany), +10dBV (consumer +12.2 dBu)
Audio Converters 24 bit, 48/96 KHz
User Controls External Dipswitch:
Channel 1/2: A/D, D/A
Channel 3/4: A/D, D/A
Audio Level 1
Audio Level 2
Size 5.8" x 3.1" x 1 (147 x 79 x 25mm)
Power 5-18V, 3 watts. Requires power supply.
Reference Loop 75 Ohm (unterminated). HD/SD Sync, AES-11, or
Wordclock (48/96 KHz)
