AJA HD10AVA SD/HD Audio/Video A/D Converter User Manual — Introduction
Introduction
The HD10AVA is a miniature, high-quality, audio/video, HD/SD A/D converter.
The HD10AVA automatically detects the video input format and embeds the audio
inputs in the SDI/HD-SDI outputs. The HD10AVA is useful for adding an SDI/
HD-SDI audio/video output to tape decks or any professional video equipment with
analog outputs. The HD10AVA is especially useful for adding HD-SDI outputs to
most HDV cameras or decks by using the component outputs of such devices. The
HD10AVA uses a breakout cable for audio/video inputs and provides 3 SDI-HD-
SDI on BNCs.
Features
• High-Quality SD/HD Audio/Video A/D Converter
• SD Component, Composite or Y/C Video Input
• HD Analog Component Video Input
• Four Channel Balanced Analog Audio Input
• 3 SDI/HD-SDI w/embedded Audio Outputs
• 12 Bit Video, 24 Bit Audio A/Ds
• Automatic Multi-Standard
• External Dip Switch Configuration
• 5-18V Power
Video SD Input Modes Supported
• 480i component BETA US
• 480i component SMPTE US
• 480i S Video US
• 480i composite US
• 480i component BETA Japan
• 480i component SMPTE Japan
• 480i S Video Japan
• 480i composite Japan
• 576i component SMPTE
• 576i S Video
• 576i composite
HD Input Modes Supported
• 1080p component 23.98psf/24psf
• 1080i component 50/59.94/60
• 720p component 50/59.94/60
Audio
The HD10AVA supports 4 analog audio input channels (2 stereo pairs) at 48 KHz.
These inputs are connected via a supplied cable that attaches to a D-connector on the
converter. Connections are made via high quality XLRs.
