AJA HD10AVA SD/HD Audio/Video A/D Converter User Manual — Specifications
Specifications
Item Specification
Formats 1080i 50/59.94/60 Hz
1080psf 23.98/24 Hz
1035i 50/59.94/60 Hz
720p 50/59.94/60 Hz
Video Inputs HD component YPbPr, (SMPTE-274), 3 BNC
SD component/composite/YC (S Video), 3 BNC
Video Outputs SDI, HD-SDI, SMPTE-259/292/296, 3 BNC
Audio Inputs 4 Channel Balanced, 4 XLR
Video A/D 12 bits
Audio A/D 24 Bits, 48Khz
Audio levels +10dBu, +12dBu, +18dBu, +24dBu, Full Scale Digital
User Controls External Dipswitch:
Component/Composite (SD)
Composite/YC (SD)
Pedestal Present (on/off) (SD)
Audio Input Level
Embed Audio on/off
Size 5.8" x 3.1" x 1 (147 x 79 x 25mm)
Power 5-18V, 5 watts. Requires power supply.
