AJA HD10AVA SD/HD Audio/Video A/D Converter User Manual — I/O Connections
I/O Connections
HD10AVA and Cable, Side View
Configuration
Determined by
DIP switch on
other side of
Converter
Analog Input
+ 5 to 18VDC
Power
Input
HD/SD-SDI
D-connector
(attaches to
supplied cable)
Cable
Not Shown
To Scale
Output 1 BNC
HD/SD-SDI
Output 2 BNC
HD/SD-SDI
Output 3 BNC
