AJA HD10AVA SD/HD Audio/Video A/D Converter User Manual — User Controls
Format Selection Matrix For Switches 1, 2, 3 and 7
The following table shows the combinations of DIP switch settings required to configure
various formats.
Note:
HD formats are auto-detected and configured for YPbPr component.
Switch 4 (AUDIO LVL)—Selects Whether Audio Input Levels are
Professional Or Consumer. Affects all 4 Inputs.
:
Note:
Professional audio equipment uses much higher levels than consumer equipment:
nominal professional levels are +4/-6dBu, consumer levels are -8/-14dBu.
Switch 5 (AUDIO LVL)—Control Whether Audio Levels are High or
Low. Affects all 4 Inputs.
Format DIP Switch #1
COMP-CMPST
DIP Switch #2
S-VIDEO
DIP Switch #3
PEDESTAL
DIP Switch #7
NTSC-J
SD NTSC Composite RIGHT LEFT LEFT LEFT
SD NTSC S-Video RIGHT RIGHT LEFT LEFT
SD NTSC/PAL/NTSC-J
Component-SMPTE/N10
LEFT n/a RIGHT LEFT
SD NTSC Component-BETA LEFT n/a LEFT LEFT
SD PAL Composite RIGHT LEFT n/a n/a
SD PAL S-Video RIGHT RIGHT n/a n/a
SD NTSC-J Composite RIGHT LEFT n/a RIGHT
SD NTSC-J S-Video RIGHT RIGHT n/a RIGHT
SD NTSC-J Component - BETA LEFT n/a n/a RIGHT
LEFT (PRO) RIGHT (CSMR)
Professional Levels.
(See Level Selection Matrix
Table)
Consumer Levels.
(See Level Selection Matrix Table)
LEFT (HIGH) RIGHT (LOW)
High Level
(See Level Selection Matrix
Table)
Low Level
(See Level Selection Matrix Table)
