HD5DA Mini-Converter v2.0 www.aja.com
6
Appendix A: Specifications
Video
Input
SDI Video Input HD-SDI, SD-SDI (SMPTE 292/296), 1x BNC
Output
SDI Video Output 4 HD-SDI, SD-SDI, 4x BNC, Equalizing
Return Loss
Input and Output >15dB-270Mhz
Physical
Size 8" x 2.4" x 1" (131 x 61 x 25mm)
Power Uses AJA Power Supply model DWP-U-R1 (included)
• 100-240V, 50/60Hz Universal Input
• +5VDC to 18VDC regulated, 7.5 watt capacity
• Power rating above for serial number 6277 and higher. Lower numbered units
require +5VDC only.
