Akai ADVANCE61 User Manual

1 PU008008025 Conductive Foam 1
38
1 RU1504370 Rubber Pad 2
5
1 RU1530608 Rubber Foot 6
18
1 SC0308RBNI Screw M3X8 PRN Tapping 30
21
1 SC0310BIBI SCREW M3X10 PBB 1
37
1 SC0310RBBI Screw M3X10 PPB Tapping 12
19
1 SC2608RBZI SCREW M2.6X8 PPC TAPPING 4
22
1 SC3514PBBI SCREW M3.5X14 PBB TAPPING 21
20
1 TFTVT043ALN05T0
TFT4.3 吋 VT043A-LN05-T01B 480*272 Pix 6
1
7
O'clock
1 TW61701AYAH0103 61Key Board Assembly 1
14
2 BAGL-55A CABLE CLIP 55L 1
2 CN0225405501 Flat Cable 2Pin Pitch 2.54mm Single Row 1
Length 550mm Female Header/Pin Header
2 CN1625403501 Flat Cable Type 8P*2 Pitch 2.54mm Dual 1
Row Length 350mm Female/Female Header
2 CN1625405001 Flat Cable Type 8P*2 Pitch 2.54mm Dual 1
Row Length 500mm Female/Female Header
2 KB61701AYAH01 61 Key board weighted with aftertouch 1
1 TWFSR8KEY-ADW1 FSR+Mylar Assembly 1
2 NP215AKA57 Mylar 1
48
2 OTFSR8KEY-ADW1 FSR 1*8KEY 1
6
1 TWPC13A03803 ADW3 Main PCB Assembly 1 10
2 CS047C5002NPO CCAP SMD 4.7pF/50V ±0.25pF 0402 NPO 6 C6,7,9~12
2 CS102J5002NPO CCAP SMD 1nF/50V ± 5% 0402 NPO 9 C23~31
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 29 C1,5,8,34~42,44,47,50~64
2 CS105K1605X7R CCAP SMD 1uF/16V 10% 0805 X7R 4 C65~68
2 CS105K5006X7R CCAP SMD 1UF/50V 10% 1206 X7R 1 C3
2 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 3 C2,43,46
2 CS180J5002NPO CCAP SMD 18pF/50V 5% 0402 NPO 2 C32,33
2 CS225K1605X7R CCAP SMD 2.2uF/16V 10% 0805 X7R 2 C48,49
2 DISR26 Schottky Barrier Rectifier 1 D1
2 FCN1R0503001 FCN Up Touch ZIF SMD Pitch=0.5mm 30P 1 FCN1
2 FCN1T0504001 FCN Down Touch ZIF SMD Pitch=0.5mm 40 2 J8,9
Pin
2 FCN1T0504002 FCN Up Touch ZIF SMD Pitch=0.5mm 40P 1 FCN2
2 IC74AHC541PW IC 74AHC541PW Octal Buffer/Line driver 1 U18
3-state output TSSOP-20
2 ICAP3031KTR-G1 IC AP3031KTR-G1 SOT-23-6 1 IC1
2 ICEM63A165TS-6G IC EM63A165TS-6G 16M*16bit SDRAM TSOP 1 U17
II-54
2 ICYH103M17 IC(ICSTM32F429IGT6+Program) LQFP-176 1 U16
3 ICSTM32F429IGT6 IC STM32F429IGT6 MCU 32Bit 2MB Flash 1 (U16)
LQFP-176
2 ICYH103M18 IC(ICMX25L3235EM2I+Program)SOP-8 1 U2
3 ICMX25L3235EM2I IC MX25L3235EM2I-10G 32Mbit Flash Memory 1 (U2)
with 104MHz SPI Multi I/O Bus SOP-8
2 PC13A038 Main PCB 6-Layer FR-4 119*71mm 1.6T 1 -
2 RS000010J03 RES 0Ω 5% SMD 0603 6 R7,11,16,17,19,20
2 RS000108J05 RES 1.0 Ω 5% SMD 0805 1 R250
2 RS001010F03 RES 10Ω 1% SMD 0603 1 R267
2 RS003310F03 RES 33Ω 1% SMD 0603 1 R164
2 RS004716F02 RES 47Ω 1% SMD 0402 29 R208,227,228,230,232,234,236,238,240
R245~249,251,252,254~266
2 RS010016F02 RES 100Ω 1% SMD 0402 66 R161,162,165,166,168~170,173~197,199~207
R209~219,221,223~226,229,231,233,235,237
