Akai ADVANCE61 User Manual

R239,241,244,340
2 RS010K10F03 RES 10K 1% SMD 0603 9 R2,4,6,9,15,220,222,243,268
2 RS05R110F03 RES 5.1Ω 1% SMD 0603 1 R8
2 RS1K8710F03 RES 1.87K 1% SMD 0603 1 R18
2 RS4K7510F03 RES 4.75K 1% SMD 0603 2 R24,160
2 TE591271001 Pin Header 180° Pitch:1.27mm Dual Row 1 J5
5Pin*2 SMD
2 TE682000501 Pin Header 90° Pitch:2.0mm Single Row 5 1 J7
Pin SMD
2 UH160808T-600Y BEAD 60Ω @100MHz 3A ±25% 0603 2 L1,2
2 UHMLPS-4018-4R7
INDUCTOR 4.7uH 1.7A ±20% SMD 4*4*T1.8mm
1 L6
2 XTM25000X602 Crystal 25MHz 49US(18pF) SMD Fundamental 1 X1
1 TWPC13A03901 TOP Right PCB Assembly 1 23
2 AA822524X IC SN74HC165PW 1 U12
2 AL0-09-0044 Variable Resistor 8 P1~8
2 AL2-49-0070 Diode BAV70 4 D42~45
2 AL2-65-0114 IC 74AHC1G14 SOP-5 1 U10
2 AL2-71-1324 IC LMV324 SOP-14 1 U23
2 AL2-73-4052 IC HEF4052BT Dual 4-channel analog 2 U20,21
multiplexer/demultiplexer SOP-16
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 29 C16~21,67~84,86,89,92~94
2 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 1 C91
2 CS561J5002NPO CCAP SMD 560PF/50V ±5% 0402 NPO 4 C85,87,88,90
2 FCN1T0504002 FCN Up Touch ZIF SMD Pitch=0.5mm 40P 1 J1
2 IC74AHC14PW MICONIC 1 U22
2 ICSN74LV595APWR
IC 74LV595A 8-bit SERIAL SHIFT W/LATCHES
4 U11,13,14,15
TRI-STATE TSSOP-16
2 LDJ1M1F1BB7R4S3 Liquid-emitting Diode Red/Green/Blue SMD 8 D31~38
0603 angle 120°
2 LDKPT-1608SYCK Liquid-emitting Diode Yellow SMD 0603 8 D23~30
angle 120°
2 PC13A039 TOP Right PCB 2-Layer FR-4 393.5*111.5mm 1 -
1.6T
2 RS000010J03 RES 0Ω 5% SMD 0603 4 R289~292
2 RS001K10F03 RES 1K 1% SMD 0603 4 R274,278,282,286
2 RS001M10F03 RES 1M 1% SMD 0603 12 R155~158,269~272,275,279,283,287
2 RS010K10F03 RES 10K 1% SMD 0603 1 R110
2 RS016210F03 RES 162Ω 1% SMD 0603 8 R133,136,139,142,145,148,151,154
2 RS022110F03 RES 221Ω 1% SMD 0603 4 R119~121,130
2 RS047510F03 RES 475Ω 1% SMD 0603 12 R122~129,273,277,281,285
2 RS33R210F03 RES 33.2 1% SMD 0603 16 R131,132,134,135,137,138,140,141,143
R144,146,147,149,150,152,153
2 RS4K7510F03 RES 4.75K 1% SMD 0603 12 R111~118,276,280,284,288
2 SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 8 S27~34
1 TWPC13A04003 ADW3 Rear IO PCB Assembly 1 29
2 AA822748X Diode BAV99 3 D6,50,51
2 AL2-50-4149 Diode Single 1N4148 100V 200mA SOT-23 1 D5
2 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 1 Q4
MMBT4401LT1 NPN SOT-23)
2 AL2-51-4403 Transistor 2N4403 PNP SOT-23 2 Q2,3
2 AL2-54-6306 Mosfet FDC6306P P-CH SSOT-6 1 Q1
2 AL2-71-1324 IC LMV324 SOP-14 1 U25
2 AL2-73-4052 IC HEF4052BT Dual 4-channel analog 1 U28
multiplexer/demultiplexer SOP-16
2 AL4-00-0002 MIDI Jack 8P 90° Female 2 J4,8
