Akai ADVANCE61 User Manual

2 AL4-02-0007 Jack 1/4 Stereo 7-Pin Fem Mini W/Grnd 2 J13,14
Lug Straight
2 AL4-08-0402 Con USB 4-Pin Female PC-MNT Horizontal 1 J7
2 AL4-14-0116 CONNECTOR 6P DIL 2 J15,16
2 AL4-15-0004 Connector 4P 2.54 180° 2 J11,12
2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 4 C5,6,103,104
2 CS103K2502X7R CCAP SMD 0.01UF/25V 10% 0402 X7R 5 C114,117~120
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 28 C4,7~13,15,91,95,97,98,99,102,105~108
C110,113,115,116,121~125
2 CS105K1605X7R CCAP SMD 1uF/16V 10% 0805 X7R 1 C100
2 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 3 C14,16,92
2 CS106K2506X5R CCAP SMD 10UF/25 ±10% 1206 X5R 2 C2,3
2 CS225K1605X7R CCAP SMD 2.2uF/16V 10% 0805 X7R 1 C1
2 CS226K0606X5R CCAP SMD 22uF/6.3V 10% 1206 X5R 2 C93,94
2 DIBAW56 Switch Diode BAW56 SOT-23 2 D1,3
2 DIPHLTV-356T-B optical coupler Diode LTV-356T-B 1 U2
2 DISDBAT54SSM Diode BAT54S 30V 0.2A SOT-23 2 D48,52
2 DISDMBRA340T3G
Shottky diode DISDMBRA340T3G SMD 3A 40V
2 D2,4
2 DIZDMMBZ5236BSM Zener Diode MMBZ5236BLT1G 7.5V SOT-23 1 D46
2 FCN1T0504001 FCN Down Touch ZIF SMD Pitch=0.5mm 40 1 J2
Pin
2 ICLM393DGKR IC LM393DGKR MSOP-8 1 U1
2 ICRT8299AZSP IC RT8299AZSP 3A 24V 500KHz Synchronous 1 U24
2 Step-Down converter SOP-8
2 ICSN74AHCT1G126 IC SN74AHCT1G126DBVR TSSOP-5 1 U26
2 ICUSBLC62SC6 IC USBLC62SC6 SOT-23-6L 1 D47
2 ICYH102M27 IC(ICSTM32F100C4T6+Program) LQFP-48 1 U3
3 ICSTM32F100C4T6 IC STM32F100C4T6B LQFP-48 1 (U3)
2 JKDJ-0702B-020 DC Base 2.0MM 1 J1
2 PC13A040 Rear IO PCB 2-Layer FR-4 146*75mm 1.6T 1 -
2 PT1304702 PLATE 1 (J8)
2 RS000010J03 RES 0Ω 5% SMD 0603 7 R9,14,37,298,318,322,325
2 RS000016J02 RES 0Ω 5% SMD 0402 14 R19~26,28,29,34,35,58,59
2 RS001K10F03 RES 1K 1% SMD 0603 7 R27,291,292,293,329,330,339
2 RS001M10F03 RES 1M 1% SMD 0603 3 R304,310,328
2 RS010K10F03 RES 10K 1% SMD 0603 17 R1~8,11,16,18,31,32,39,40,41,338
2 RS016K10F03 RES 16K 1% SMD 0603 1 R290
2 RS01K110F03 RES 1.1K 1% SMD 0603 1 R13
2 RS01K510F03 RES 1.5K 1% SMD 0603 1 R297
2 RS022110F03 RES 221Ω 1% SMD 0603 1 R15
2 RS030K10F03 RES 30K 1% SMD 0603 1 R287
2 RS047510F03 RES 475Ω 1% SMD 0603 6 R12,17,302,306,320,332
2 RS05K110F03 RES 5.1K 1% SMD 0603 1 R295
2 RS080610F03 RES 806Ω 1% SMD 0603 2 R10,317
2 RS100K10F03 RES 100K 1% SMD 0603 3 R289,294,327
2 RS11K810F03 RES 11.8K 1% SMD 0603 3 R303,309,321
2 RS15K810F03 RES 15.8K 1% SMD 0603 4 R301,305,319,331
2 RS1K3310F03 RES 1.33K 1% SMD 0603 1 R326
2 RS22K110F03 RES 22.1K 1% SMD 0603 1 R324
2 RS2K3210F03 RES 2.32K 1% SMD 0603 1 R337
2 RS33K210F03 RES 33.2K 1% SMD 0603 1 R333
2 RS3K3210F03 RES 3.32K 1% SMD 0603 4 R307,311,313,315
2 RS470K10F03 RES 470K 1% SMD 0603 1 R288
2 RS47K510F03 RES 47.5K 1% SMD 0603 3 R308,312,336
2 RS47R510F03 RES 47.5Ω 1% SMD 0603 2 R299,300
2 RS4K7510F03 RES 4.75K 1% SMD 0603 2 R323,335
2 RS820K10F03 RES 820K 1% SMD 0603 1 R296
