Remote control (RC)
Trouble Action
RC does not function Check the battery installation.
Point the RC at the remote control sensor.
Stay within 8 metres of the appliance.
Technical data8.
Parameter Value
Voltage 220V
AC
/ 50 Hz
Power consumption 27 W
Standby power consumption 8,5 W
Max power output 15 W x 5 (RMS) + 30 W (RMS)
Frequency response +/- 1.5 dB (20 Hz ~ 20 kHz)
Headphones output impedance 32 Ω
Dimensions (W x H x D) 435 x 55 x 259 mm
Weight 2.3 kg
Frequency range
Parameter Value
AM radio 522 ~ 1620 kHz
FM radio 87.5 ~ 108 mHz
Disc output
Parameter Value
Laser type Semiconductor
Frequency range 20 Hz ~ 20 kHz
Signal/noise ratio > 80 dB (1 kHz)
Dynamic range ≥ 70 dB (1 kHz)
Distortion ≤ -60 dB (1 kHz)
Wow and utter Below the limit of the appliance
Television system PAL/NTSC
Region code 2
