Akai APC Key 25 Service Manual

AD11 Level 1 BOM list
Part No.
Description
Qt
y
051491000 GIFT BOX REV.D FOR AD11 "ROHS"(ARTWORK REV.D) 1
051491100 OUTER CARTON REV.A FOR AD11 "ROHS" 1
021184200 KNOB ROTARY ABS FOR AD01 "ROHS" 1
021184700 KEY STROKE SILICON RUBBER 13-KEY "ROHS" 1
021185400 KEY ABS AS 7-KEY WHITE FOR AD02 "ROHS" 1
021185501 KEY ABS AS 5-KEY BLACK REV.B FOR AD02 "ROHS" 1
021185601 REAR KEY WHITE ABS REV.B FOR AD02 "ROHS" 1
021185700 KEY STROKE SILICON RUBBER 12-KEY "ROHS" 1
021491000 TOP COVER ABS BLACK FOR AD11 "ROHS" 1
021491100 BOTTOM COVER ABS FOR AD11 "ROHS" 1
021491200 54KEY RUBBER BOTTON REV:0.3 FOR AD11 "ROHS" 1
021491300 6KEY RUBBER BOTTON REV:0.3 FOR AD11 "ROHS" 1
061243000
CABLE FFC P=1mm 16PIN L=150mm CONTACT ON
DIFFRENT SIDE "BINGCHUANG" 1.0*16P*150mm*A "ROHS"
1
105-AD03-64 PCB ASSY KEYBOARD FOR AD03 "ROHS" 1
105-AD11-61 PCB ASSY MAIN BOARD AD11 "ROHS" 1

Akai APC Key 25 Specifications

General

MIDI-keyboard number of keys	25 keys
Product color	Black
Interface	USB
Power source type	-
