Part III
LED test
The main purpose of this test is to make sure all LED are ok and the color are correct.
Green LED test
1 Press the Green LED? Button in the applcation by using the mouse.
2 The LED on the indicated area will on. Make sure all the LED are on and the color or brightness
are even among each type of LED.
Figure 11: All LED ON.
APC20 TEST PROCEDURES
