Akai EIE Pro

TECHNICAL SPECIFICATIONS
USB AUDIO INTERFACE
Sampling Rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Resolution: 24-bit
Interface: USB 2.0
ANALOG INPUTS
Frequency Response: 20 Hz to 21 kHz (+
0.05dB)
Dynamic Range (@-60dB input): 96 dB, A-weighted
S/N: 96 dB, A-weighted
THD+N: 0.001% @ 1 kHz / -0.1 dBFS
Crosstalk: 93 dB @ 1 kHz / -0.1 dBFS
Pre-amp THD+N: 0.018%
Mic gain (MIC): +9 dB to + 51.5 dB
Mic impedance: 6.3 KΩ
Line gain: -10.5 dB to +41 dB
Line impedance: 55 KΩ
Guitar gain: +1.6 dB to 53.1 dB
Guitar impedance: 102 KΩ
Insert:
Input sensitivity: 0 dBFS @ +6 dBV
Input impedance: 10 KΩ
ANALOG OUTPUTS
Output level: +6 dBV @ 0 dBFS
Frequency Response: 20 Hz to 20 kHz (+
0.25 dB)
Dynamic Range (@-60dB input): 98 dB, A-weighted
S/N: -100 dB, A-weighted
THD+N: 0.006% @ 1 kHz / 0 dBFS
Crosstalk: 97 dB @ 1 kHz / 0 dBFS
HEADPHONES
32-Ω load:
Unclipped output power: 10 mW @ 1 kHz
Frequency Response: 20 Hz to 20 kHz (+
0.25 dB)
S/N: -100 dB, A-weighted
THD+N: 0.007% @ 1 kHz / 0 dBFS
Crosstalk: 95 dB @ 1 kHz / 0 dBFS
600-Ω load:
Unclipped output power: 3.4 mW @ 1 kHz
Frequency Response: 20 Hz to 20 kHz (+
0.25 dB)
S/N: -100 dB, A-weighted
THD+N: 0.003% @ 1 kHz / 0 dBFS
Crosstalk: 95 dB @ 1 kHz / 0 dBFS
• The unit can be used in the following electromagnetic environments: residential, commercial and light industrial, urban
outdoors. This apparatus is not intended for rack-mounting.
• The maximum cable length for audio input and output is 10m.
• Peak inrush current: 656 mA
