SERVICE MANUAL
8
1. PC BOARD BLK
The PC Board Block may contain several PC Boards. They appear
under its block name without their individual part number. If one of
the PC Board is required, you need to order the whole PC Board block.
The individual PC Board is not available separately.
Ref.No Part No. Description
1 BA-L8016A020A PC(#) D2G BLK D2G
# PC MAIN BLK
# PC OPERATION BLK
2. PC MAIN BLK
Ref.No Part No. Description
D2 ED-386225J D SILICON 1N4002 T26 100/1.0A
IC1 EI-403306J IC NJM4558L
IC11 EI-403306J IC NJM4558L
IC12 EI-403306J IC NJM4558L
IC13 EI-403306J IC NJM4558L
IC14 EI-403306J IC NJM4558L
IC15 EI-403306J IC NJM4558L
IC16 EI-403306J IC NJM4558L
J1 EJ-812069J PHONE J HTJ-064-13H 6.3
J2 EJ-812069J PHONE J HTJ-064-13H 6.3
J3 } EJ-812072J SOCKET DC HTJ-020-05A 1P
RL1 EQ-820421X RELAY SIG RY-9WK 1TR 9V
W902 EW-820443X WIRE ASSY MS-2-120-UL LEADWIRE
3. PC OPERATION BLK
Ref.No Part No. Description
100 SE-820494X SPACER LED L=7.0
D141 ED-812087J D LED L-934SRD-G RED
D142 ED-418682J D ZENER H HZS6A2 T26
IC101 EI-403306J C NJM4558L
IC102 EI-403306J C NJM4558L
TR101 ET-364492 TR DTC114TS T05
TR102 ET-366753 TR DTA114ES T05
VR101 EV-820415X VR ROTARY RK09L1141F20B15 B104
VR102 EV-820485X VR ROTARY RK09L1141F20A15 A104
VR111 EV-820444X VRSLIDE RS2511130615W24 W203S
VR112 EV-820444X VRSLIDE RS2511130615W24 W203S
VR113 EV-820444X VRSLIDE RS2511130615W24 W203S
VR114 EV-820444X VRSLIDE RS2511130615W24 W203S
VR115 EV-820444X VRSLIDE RS2511130615W24 W203S
VR116 EV-820444X VRSLIDE RS2511130615W24 W203S
VR121 EV-820444X VRSLIDE RS2511130615W24 W203S
VR122 EV-820444X VRSLIDE RS2511130615W24 W203S
VR123 EV-820444X VRSLIDE RS2511130615W24 W203S
VR124 EV-820444X VRSLIDE RS2511130615W24 W203S
VR125 EV-820444X VRSLIDE RS2511130615W24 W203S
VR126 EV-820444X VRSLIDE RS2511130615W24 W203S
4. FINAL ASSEMBLY BLK
Ref.No Part No. Description
1 SP-820403X PANEL TOP D2G
2 ZW-384700J1 PROP 2 F.SCREW L=10
3 ZS-355511 BID30X06STL BNI
4 ZS-418385J BT BID30X06STL BNI EARTH LOCK
5 SM-820407X MASK SLIDE
6 SH-820406X HANDLE
7 ZS-379405 BID30X06STL CMT
8 ZW-820401X PROP 6 M.SCREW L=20
9 ES-812047J SW PUSH SB-285(METAL) 02-02N
10 ZW-812439J SW120STL CMT
11 ZW-812440J PW122X160X050STL NI3
12 SC-820409X HOLDER BATTERY
13 ZS-820455X BT CTS30X06STL BNI
14 SP-820405X COVER BOTTOM D2G
15 SA-820495X FOOT K13W
16 ZS-820564X ST PAN30X10 STL BZN C080
17 SC-820412X COVER BATTRY
18 SE-820411X CUSHION BATTERY
19 ZS-820413X SCREW COSMETIC
20 ZW-820480X SLIT W25X060X050PSL
21 SK-820458X CAP(BLACK) 2.8X10X1.5
22 SK-820408X KNOB VOLUME
