3
EDITING PRESETS
This section outlines the editable items for each preset. Items #1-4 are editable for every pad. Items #5-7
are editable for every knob.
1. NOTE # – Click on this field and drag up or down with the mouse (or use your keyboard's or keys)
to change the MIDI Note Number the pad will send.
2. PC # – Click on this field and drag up or down with the mouse (or use your keyboard's or keys) to
change the MIDI Program Change number the pad will send.
3. CC # (PAD) – Click on this field and drag up or down with the mouse (or use your keyboard's or
keys) to change the MIDI Control Change number the pad will send.
4. PAD BEHAVIOR – Click this button to select whether the LPD8's pads will function as a "Momentary"
or "Toggle" switch.
5. CC # (KNOB) – Click on this field and drag up or down with the mouse (or use your keyboard's or
keys) to change the MIDI Control Change number the knob will send.
6. LOW VALUE – Click on this field and drag up or down with the mouse (or use your keyboard's or
keys) to change the lowest possible value the knob will send.
7. HI VALUE – Click on this field and drag up or down with the mouse (or use your keyboard's or
keys) to change the highest possible value the knob will send.
SPECIFICATIONS
Number of presets: 4
MIDI output channels over USB: 16
Drum pads: 8 (velocity-sensitive)
Knobs: 8
Inputs/outputs: 1 USB port
Power: < 100 mA, 5V DC via USB
Dimensions (W x D x H): 310 mm x 80 mm x 28 mm
Weight: 34 g
