Akai MPC 2500 Quick Start Manual

11
 See “Input Thru Function” section of the Operator's Manual. (on page 94)
 See “Chapter 9 : Q-Link Slider & Knob” section of the Operator's Manual. (on page 49)
This manual only describes the basic operation of the MPC2500. The MPC2500 has a lot more features for your music
creation. Please read the Operator's Manual to learn the operation and functions of the MPC2500.
Have fun with the MPC2500!
 Input Thru function
The MPC2500 can mix an incoming audio signal from REC IN or
DIGITAL IN with the internal playback from the MPC2500. You
can also control level, pan, cut-off frequency and resonance of the
incoming signal with the Q-Link sliders and knobs in real-time.
 Q-Link sliders & knobs
By using the Q-Link sliders and knobs, you can control parameters
such as filter, tune, etc. For controlling the parameter in a Pad,
there are two ways - “NOTE ON” and “REAL TIME.”

Akai MPC 2500 Specifications

General

Polyphony	32 voices
Sampling Frequency	44.1 kHz
Sampling Bit Depth	16-bit
Maximum RAM	128 MB
Sequencer	Yes
Type	Sampler/Sequencer
Sequencer Resolution	96 ppq
Digital I/O	S/PDIF In/Out
Power Supply	Internal
Pads	16 velocity and pressure-sensitive
Storage	CompactFlash
Effects	4 internal effects processors
MIDI	2 In, 4 Out
Display	240 x 64 pixel LCD
Analog Outputs	8
Sample Memory	128 MB max
Audio Outputs	8
Audio Inputs	2
Weight	14.5 lbs
