DIRECT MON and MAIN VOL are all the way up, maxed.
Calibration
The user may need to calibrate the Unit, which is much like other recent testers.
the password is “numark”
This unit requires every routing to be calibrated, these are the values that worked in
Rhode Island on newer hardware.
Routing 1 – Stereo out to combo Jack with the top set to MIC/LINE and the back set to
MIC
Routing 2 – Stereo out to combo Jack with the top set to MIC/LINE and the back set to
LINE
Routing 3 – Assignable Mix Out to RCA, with the top switch set to PHONO and the back
switch set to LINE
Routing 4 – Assignable Mix Out to RCA, with the top switch set to PHONO and the back
switch set to PHONO
Routing 5 – Headphone Out to Combo Jack with the top set to MIC/LINE and the back
set to LINE
