2 ICYH103M13 IC(STM32F102RBT6+Program)TQFP-64 1 U4
3 ICSTM32F102RBT6 IC STM32F102RBT6 TQFP-64 1 (U4)
2 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 0603 16
LED17~32
angle 120°
2 PC14A010 FSR PCB 2Layer FR-4 187x156mm 1.6T 1 -
2 RS000008J05 RES 0Ω 5% SMD 0805 5 R2,14,17,18,28
2 RS001K08F05 RES 1K 1% SMD 0805 16
R67~82
2 RS002208F05 RES 22Ω 1% SMD 0805 2 R5,6
2 RS004710F03 RES 47Ω 1% SMD 0603 1 R26
2 RS006808F05 RES 68Ω 1% SMD 0805 16
R27,29~33,57~66
2 RS010008F05 RES 100Ω 1% SMD 0805 1 R34
2 RS010K08F05 RES 10K 1% SMD 0805 9 R8,11,15,16,19,22,500,501,502
2 RS01K508F05 RES 1.5K 1% SMD 0805 5 R1,3,4,7,9
2 RS022008F05 RES 220Ω 1% SMD 0805 5 R10,12,13,20,21
2 RS047008F05 RES 470Ω 1% SMD 0805 4 R37,38,39,40
2 RS06K808F05 RES 6.8K 1% SMD 0805 4 R23,24,35,36
2 XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamental 1 X1
1 TWPC14A01302 Function PCB Assembly 1
2 AL3-02-0035 LIQUID-EMITTING DIODE RED ASTIGMATISM 4 LED200~203
DIP
2 BALE42206-0A LED Holder 4 (LED200~203)
2 BALED2X2 LED FIXED PLATE 1 (LED204)
2 CC10450T C.CAP 0.1UF/50V 6 C200,203,206,210,213,216
2 EC10616TS Capacitor Electrolytic 10uF/16V 4*5mm 1 C201
2 FCN2R1001401 FCN Dual Touch 90° Pitch:1.0mm 14P 2 J200,201
2 JW5206T Jumping Wire 9 J1~9
2 LD-005HLV Red LED 1 LED204
2 PC14A013 Main PCB 1Layer FR-1 1.6T 187x68mm 1 -
2 R10316 RES 10K 1/8W 6 R210~215
2 SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 6 SW200~205
2 VRR12302501 Potentiometer Rotary 12.5k 2B*2 25mm 6 R200~205
