Akai MPD226 Service Manual

AD27AKA21 BOM
LEVEL P/N DESCRIPTION QTY REF
0
AD27AKA21 AD27 USB5V USA 0
1 AA821535X USB 2.0 Cable 1m A/B Type Black 1
1
BASJ5012B PU Stand 6
10
1 CA030000503 TRS Cable 50mm 3.5φ/MIDI Type Black 2
1
CN0100000501 Flat Cable GND Wire Black Length 50mm 1
24
Line/Female
1
EVA1504479 EVA 1
1 FFC1610000501 FFC 16Pin Pitch:1.0mm Length:50mm 1
20
1
FFC1610001501 FFC 16Pin Pitch:1.0mm Length:150mm 1
21
1 GEAKA17 Ableton Card 1
1
GEAKA20 Generic Card 1
1 LAC22AKA365 Serial Number Label 1
1
LAC22AKA42 Sticker S/N Ableton 1
1 LAC46AKA390 Istruction Label(IOS MODE) 1
1
LAC57AKA399 Safety Label 1
1 LAC62AKA366 Bar Code Label(CODE39) 0.5
1
LAC62AKA372 Bar Code Label(GTIN14) 0.5
1 LAC67YAH261 Label φ8mm Green 0.5
1
LCMWH2004B LCM WDH0235-TMI-JTV 6O'clock 1
13
1 NM1504403 FELT-45-ADHESIVE 4
22
1
NP215AKA41 Name Plate 1
12
1 OTFSR16KEY-AD33 FSR 16KEY 1
5
1
PAD27AKA21 Packing Assembly 1
2 AL7-51-0226-M Safety Manual 1
2
CGAD27310AKA01 Gift Box 1
2 CTAD27513AKA01 Shipping Carton 0.5
2
OPAD27AKA01 Instruction book 1
2 PE230190402B07 Pe Bag 1
2
PLAD2701 Polyfoam(Left) 1
2 PLAD2702 Polyfoam(Right) 1
2 SD38030000 Soft Sheet 1
1 PT1110685 Button Push 6
15
1 PT1504329 Light Pipe 7
25
1 PT1510611001 Power Button(Painting) 1
23
2 PT15106110 Power Button 1
1 PT1510611301 Knob Print 1
11
2 PT15106113 Knob 1
1 PT15106125 Button(B;clear) 8
1 PT15106150 Knob 4
1
1 PT15106151 Buttom(B;Cool Gray 6C) 2
16
1 PT15106192 Button(Pantone 187C) 1
18
1
PT151063801 FADER INDICATE PAINTING WHITE 4
2
2 PT1510638 FADER 4
1 PT151063904 Bottn Cursor(Black)Printing 1
17
2 PT1510639 BUTTON CURSOR(BLACK) 1
1 PT153004302 Top Panel(Print/Paint) 1
3
2
PT1530043 Top Panel(Black) 1
1 PT1530335 Bottom Panel(Red) 1
8
1 RU1510638 Rubber Knob 1
4

Akai MPD226 Specifications

General

Current	1 A
Input voltage	6 V
Power supply type	AC
Product color	Black
Number of controls	36
Drum pads backlight	Yes
Number of drum pads	16
Number of mixer channels	4 channels
USB version	2.0
USB connector type	USB Type-B
USB ports quantity	1
Minimum RAM	1 GB
Minimum processor speed	1.25 GHz

Weight and Dimensions

Depth	254 mm
Width	333 mm
Height	48 mm
Weight	1300 g
