Akai MPX8 User Manual

4
Operation
Display Overview
This is an overview of MPX8's Display:
1. Kit: The number of the preset, either a
Internal Kit (with an "i" prefix) or a User
Kit (with an "e" prefix).
2. Sample Location: Displays the sample
location, either MPX8's internal sample
library or an inserted SD card (sold
separately).
3. Message: Displays information about
MPX8's current state. This will show an error message if MPX8 cannot execute a
command.
4. Sample Name: Displays the name of the selected sample from MPX8's internal sample
library or an inserted SD card (sold separately).
5. Parameters: Displays the tuning, reverb, trigger type, level, panning, and MIDI note
number.
Selecting Kits
A "Kit" includes each pad’s sample location, name and/or number, tuning, reverb level, trigger
type, volume level, panning, and MIDI note number.
To select a Kit:
1. Use the Select +/– buttons to move the cursor to
the Kit field (KIT).
2. Use the Data Dial to scroll through the kit
numbers. (Internal Kits have an "i" prefix, and
User Kits have an "e" prefix.)
3. When the desired Kit number is shown, wait a
few seconds—the Kit will load automatically.
12
3
4
5

Akai MPX8 Specifications

General

Sample rate	48 kHz
Mixer section	-
Product color	Black
Drum pads backlight	Yes
Number of drum pads	8
Built-in optical drive	No
Headphone outputs	1
Headphone connectivity	3.5 mm
Apple docking compatibility	Not supported
Current	1 A
Input voltage	5 V
Power supply type	USB

Weight and Dimensions

Depth	102 mm
Width	295 mm
Height	33 mm
Weight	450 g
