S. AUTOMATIC SHUT-OFF (DECK AND AMPLIFIER S)
When the SHUT.OFF BUTTON @ is push ed in ( Figure 12 @), the deck
and
th e ampli fie rs are conn ec ted to th e TENSIO:-i ARM @ micro-
sw it c h. If the tap e should br eak, p il e up. or pass e ntire ly thr ough to
the tak e up reel, th e TENSION ARM @ will reach th e po sition
shawn in
Figure 12 ® and the de ck and amplifiers w ill be turn ed off
a
utom atica ll y.
L..P.;.O;IL. •• .. v-" .. '-";_TooF ... w;_;o;_ __ ..,:R~fP~I~Aic__._~ REVR!, SHUI Otr
6. AUTOMATIC REVERSE (MEYER)
i\utomati c · ·e ver se is used f or pl ay ba ck only. Wh en the meter is used
for
au t om a ti c rever se th e X- 355 w ill give co ntinu ous playback in bath
direc ti ons betw een any two po ints (A a nd B) se lected on the tap e.
(A) Push in on th e DIAL OFF BUTTON @ and rotate it clockwi se
until th e black index ma rk point s s tr aig ht up .
(B) Align the '·0" on the
TAPE COUNT MET ER @a nd th e r ed
index mark on the SET DIAL @ with the bl ack index mark on
th e DI AL OFF B UTTON @ ( Fi g ur e 13@)
Thi s st ep es t ab li shes point A on the tape.
(C)
Advance the tape, by eith er th e PLA Y BUTTON @ or th e FA ST .
FOR WARD BUTTON @.
As th e tape feeds forward , the TAPE COUNT METER @ mav es
counter clockwi
se as sh awn in Fi g ur e 13® .
Push th e S TOP BUTTON @ when th e tape has a dv anced to the
de sired po int ll.
(0 ) Rotate th e SE T D IAL @ until its red index m ar k is a li gned with
th e " 0" on th e TAPE COU NT METER @ as sh awn in Fi gur e 13@.
(E) Push th e R EVE R SE B UT TO N @ ( Figur e 13@)
(F) Using th e REWI ND B UTTON @, rewind th e tape ba ck to th e
sta
rtin g point A.
As
th e tape rewinds or pl ayb ack in re ve rse, the TA PE COUNT
METER @ ma ves clockwi se . Th e sta rtin g po int A is reached
when
th e "0" on th e TAPE COUNT METER @ is a li gned with
the black index
mark on th e DIAL OFF B UT TO N @.
(G) Push the PLA Y B UTTON @.
The X- 355 w ill n ow pl ayba ck fr om po int A to po int B, and up on
reaching point B will rever
se it se lf and pl ay ba ck to poi nt A where
it w
ill reverse it se lf a ga in for pl ayb ac k to po int B. Thi s operation
will
continue a ut oma ti ca ll y, as sh aw n in Figur e 13@, until th e
STOP BUTTON @ is pu s hed Wh en th e PL A Y B UTTON @ is
pu shed a ga in, pl ayba ck w ill res um e in the forward dir ec ti on until
re ve rsai occ ur s at poi .1 t B.
®
