IMPORTANT NOTES FOR REDUCING FALSE ALARMS
1. Do not install the camera in a position facing any objects with bright lights,
including sunshine, bright lamp lights, etc.
2. Do not place the camera too close to a place where there are frequently moving
vehicles. Based on numerous tests, the recommended distance between the
camera and vehicle is 15 meters (55 feet.).
3. Stay away from the outlets, including air conditioner vents, humidifier outlets, the
heat transfer vents of the projects, etc.
4. Do not let the camera facing the mirror.
5. Keep the camera at least 1 meter away from any wireless devices in order to avoid
wireless interference, including Wi-Fi router and phones.
6. When installing the camera, it’s not suggested to make the PIR sensor vertically
face the moving objects, otherwise it may not detect the motion event. It is
suggested to make the angular between PIR sensor and detected object larger
than 10 degree.
SPEC DATA
Camera
Compression Standard
Image sensor 1080P Color Sensor 1/3CMOS
Audio Input/output Built-in microphone and speaker
Lens 3.6mm
Angle of view 120 degree
Day & night Electronic (IR-CUT filter with auto switch)
Video compression H.264
Bit rate 16Kbps~2Mbps
Dual stream Yes
Network
Image resolution 1080P (1920*1080), VGA (640*480)
Frame rate 25fps
Alarm trigger Intelligent motion detection, support PIR
Wireless Security WEP, WPA, WPA2
Remote wakeup Support
Wireless 2.4G Wi-Fi(IEEE802.11b/g/n)
Supported phone OS iOS 7 up, Android 4.0 up
Security User authentication, software encryption
17 18
Battery
General
Standby consumption 500µA
Work consumption 220mA
Operating temperature −20 °C to 50 °C
Power supply Support, optional, DC 5V/1A
IR distance Night visibility up to 15m
