Adding Phantom Power to Unbalanced Amplifier Inputs
Cleaning
To clean the metal surfaces, use methylated spirits or alcohol.
Standard Accessories
H 100 shock mount
Optional Accessories
B 18 battery power supply
MK 9/10 10-m audio cable with 3-pin XLR connectors
N 62 E AC power supply for two microphones
N 66 E AC power supply for six microphones
PF 100 studio pop filter
SA 41/1 stand adapter
ST 102 A floor stand
ST 200 heavy floor stand
W 4000 external windscreen (supplied with the C 4000 B)
Specifications
Type: condenser pressure gradient
microphone
Polar patterns: cardioid
Sensitivity at 1000 Hz: 20 mV/Pa - 34 dBV
Frequency range: 30 to 20,000 Hz (refer to frequency
response curve)
Electrical impedance: ≤ 200 ohms
Recommended load impedance: ≥ 1000 ohms
Bass cut filter slope: 6 dB/octave below 500 Hz
Preattenuation pad: -10 dB, switchable
Equivalent noise level
to DIN 45 405 (CCIR 468-2): 30 dB
Equivalent noise level
to DIN 45 412 (A-weighted): 20 dB-A
Signal/noise ratio re 1 Pa
(A-weighted): 74 dB*)
Max. SPL for 0.5% THD (0/-10 dB):200 / 630 Pa 140 / 150 dB SPL*)
Dynamic range: 120 dB (A-weighted)*)
Environment: - temperature: -10°C to +60°C
- (14°F to 140°F)
- relative humidity: 90% (+20°C/68°F),
85% (+60°C/140°F)
Power requirement: 9 to 52 V phantom power
to DIN 45 596/IEC 268-15
Current consumption: ≤ 2 mA
Connector pinout: 3-pin male XLR to IEC standard
Size: max. dia.: 53 mm (2.1 in.),
length: 159 mm (6.3 in.)
Net weight: 325 g (11.5 oz.)
*) Values for 48 V phantom power; reduce by 3 dB for 24 V and 6 dB for
12 V phantom power.
This product conforms to standards EN 50 082-1 and EN 60 065.
