7. Specifications.
9
ITEM DESCRIPTION
Power Requirements 230V AC 50 Hz (11W)max
Standby Power < 1W
Case dimensions 420mm x 355mm x 235mm
Weight 6.68Kg’s
Audio Output 2 x 2W @ 10% THD
Tuning FM 88 – 108 Mzh
AM 540 – 1600 Khz
CD Discs 8 CM ,12 CM.
Tape Standard Cassette 2 track
stereo
Vinyl Disc speed 33, 45 78 Rpm
Outputs Headphones
8. Mains Plug Wiring Diagram
If it becomes necessary to replace the Mains Plug, it should be
wired in accordance with the diagram above.
The Brown wire (Live) should be connected to the terminal (L)
The Blue wire (Neutral) should be connected to the terminal (N)
This Player is a “CLASS 2” apparatus and must NOT be earthed.
