Installing the TPMS sensors
1. Release the pressure from the tyre.
2. Remove the tyre from the rim.
3. Remove the tyre valve or old TPMS sen-
sor from the rim.
4. Clean the valve hole and the edge of rim of any
corrosive substances and dirt.
5. Unscrew the valve cap (4) from the TPMS sen-
sor (3) and loosen the screw nut (5).
6. Insert the TPMS sensor (3) into the rim from
the inside.
7. Place the screw nut (5) on the valve and tighten
to a torque of 4 Nm.
8. Mount the tyre on the rim. Make sure that the
TPMS sensor (3) is not damaged during moun-
ting.
9. Inflate the tyre.
10. Screw the valve cap (4) onto the valve.
11. Balance the wheel.
ADVICE
Install the other TPMS sensors in the
same way.
