Page 3
User instructions
Installing batteries
The CBBCAS2 unit can be powered by either mains power or battery power.
In order to utilise battery power the mains cable must be disconnected from
the unit.
1: Push the battery cover clip downwards in the direction indicated, and remove
the cover.
2: Fit 6 x C size batteries in the sequence shown, observing polarity.
3: Refit the battery cover.
NOTE: When left unused for long periods of time using battery power, it is
advised to switch the power to the OFF position to avoid battery drainage
in STANDBY mode.
Mains power
1: Connect the mains power cable to the MAINS POWER INPUT on the rear of the
unit.
2: Connect the mains plug to a UK power source and switch ON.
Radio operation
1: Set the FUNCTION SELECTOR switch to the ‘RADIO’ position.
2: Select the required band (FM.ST (Stereo), FM or MW) using the BAND
SELECTOR switch.
3: Rotate the TUNING CONTROL to set the frequency required.
4: Adjust the sound level using the VOLUME control.
5: To turn off the radio and enter STANDBY mode set the FUNCTION selector
switch the OFF/TAPE position.
230V~50Hz
230V~50Hz
OFF
