Albrecht CDS - Changing Spring Tension

18
CDS
®
Knee Brace Amputation
User Instructions
0
0,2
0
,4
0,6
0
,8
1
1
,2
1,4
1,6
1,8
2
2,2
2,4
2
,6
2,8
3
3,2
3
,4
3,6
3,8
4
4,2
4,4
4,6
4
,8
5
5
,2
5,4
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Drehmoment in Nm
Einstellungsstufen
Drehmoment in Nm bei Beugung 90°
Torque in Nm
Torque in Nm
Settings
2.3.7. Changing the spring tension
1
The spring tension can be adjusted according to the treatment progress.
2
Insert the tool as far as it will go into the side hole on the hinge. By turning
clockwise or towards + the spring tension is increased and it is decreased by
turning anticlockwise or towards -.
The intensity of the spring tension must be equal in both hinges.
11 22 22
The spring tension may be adjusted only in consultation with the
treating physician.
