Phillips head screwdriver or drill
may be required for installation
Passive
Infrared Sensor
Infrared
LED sensors
Antenna
Multi-position
Camera Stand
Thumb screw
Camera Stand
T-Bolt
7” Touch screen
Control Panel
Docking station
with Internet cable
(2) Outdoor cameras with
multi-position stands
(3) AC power adapters
(2) power extension cords
One 4 GB SD card
(2) Camera installation
screw packs
Quick Start Guide
x3
x2
7”
x2
IN THE BOX
x2
Internet
(Ethernet) Cable
Connection
AC Power Input
(AC power cable included)
Let’s Get Started
Model AWS3266
7” Touch Screen Control Panel Docking Station Indoor/Outdoor Camera
Tip: Plan the location of your cameras for optimal viewing and
proximity to AC Power outlets, (2) power extension cables are included
NOTE: Avoid installing in a location which requires the wireless
signal to pass through cement, concrete and metal structures. This
will reduce the transmission range.
AC Power cord
In-line Pairing
Button
Pull out Stand
Antenna
Reset button
Power (On/Off)
SD Card Slot
AC Power Connection
4 GB
Quick
Simple
Set Up
Tools
