OmniSwitch 2x60
page 1-2 OmniSwitch 2x60 Hardware Users Guide July 2021
OS2260-P48 Fixed-configuration chassis in a 1U form factor with:
• 48 x RJ45 PoE (802.3at) ports
• 6 x SFP (1G) ports
• Internal power supply
• 1 Fan
See “OS2x60-P48” on page 3-14
OS2260-P48X
(China model)
Fixed-configuration chassis in a 1U form factor with:
• 48 x RJ45 PoE ports
• 4 x SFP (1G) ports
• 2 x SFP+ (1G/10G) ports
• Internal power supply
• 2 Fans
See “OS2x60-P48X” on page 3-16
OS2360-24 Fixed-configuration chassis in a 1U form factor with:
• 24 x RJ45 non-PoE ports
• 2 x SFP (1G) ports
• 2 x SFP (1G) Uplink or SFP+ (10G) VFL ports
• Internal power supply
• Fanless
See “OS2x60-24” on page 3-6.
OS2360-P24 Fixed-configuration chassis in a 1U form factor with:
• 24 x RJ45 PoE (802.3at) ports
• 2 x SFP (1G) ports
• 2 x SFP (1G) Uplink or SFP+ (10G) VFL ports
• Internal power supply
• 1 Fan
See “OS2x60-P24” on page 3-8
OS2360-P24X Fixed-configuration chassis in a 1U form factor with:
• 24 x RJ45 PoE (802.3at) ports
• 2 x SFP+ (1G/10G) ports
• 2 x SFP (1G) Uplink or SFP+ (10G) VFL ports
• Internal power supply
• 1 Fan
See “OS2x60-P24X” on page 3-10
OS2360-48 Fixed-configuration chassis in a 1U form factor with:
• 48 x RJ45 non-PoE ports
• 4 x SFP (1G) ports
• 2 x SFP (1G) Uplink or SFP+ (10G) VFL ports
• Internal power supply
• 1 Fan
See “OS2x60-48” on page 3-12
OS2360-P48 Fixed-configuration chassis in a 1U form factor with:
• 48 x RJ45 PoE (802.3at) ports
• 4 x SFP (1G) ports
• 2 x SFP (1G) Uplink or SFP+ (10G) VFL ports
• Internal power supply
• 1 Fan
See “OS2x60-P48” on page 3-14
Model Number Description
