OmniSwitch 2x60 Hardware Users Guide July 2021 page 1-1
1 OmniSwitch 2x60
Refer to the information below for OmniSwitch 2x60 models and components.
Model Number Description
OS2260-10 Fixed-configuration chassis in a 1U form factor with:
• 8 x RJ45 non-PoE ports
• 4 x SFP (1G) ports
• Internal power supply
• Fanless
See “OS2260-10” on page 3-2
OS2260-P10 Fixed-configuration chassis in a 1U form factor with:
• 8 x RJ45 PoE (802.3at) ports
• 4 x SFP (1G) ports
• Internal power supply
• Fanless
See “OS2260-P10” on page 3-4.
OS2260-24 Fixed-configuration chassis in a 1U form factor with:
• 24 x RJ45 non-PoE ports
• 4 x SFP (1G) ports
• Internal power supply
• Fanless
See “OS2x60-24” on page 3-6.
OS2260-P24 Fixed-configuration chassis in a 1U form factor with:
• 24 x RJ45 PoE (802.3at) ports
• 4 x SFP (1G) ports
• Internal power supply
• 1 Fan
See “OS2x60-P24” on page 3-8
OS2260-P24X
(China model)
Fixed-configuration chassis in a 1U form factor with:
• 24 x RJ45 PoE (802.3at) ports
• 2 x SFP (1G) ports
• 2 x SFP+ (1G/10G) ports
• Internal power supply
• 1 Fan
See “OS2x60-P24X” on page 3-10
OS2260-48 Fixed-configuration chassis in a 1U form factor with:
• 48 x RJ45 non-PoE ports
• 6 x SFP (1G) ports
• Internal power supply
• 1 Fan
See “OS2x60-48” on page 3-12
