Table 7-1 5620 SAM firewall requirements (continued)
Default port Type Encryption Description
12300 - 12307 TCP None. These ports are used for detecting communication failures between
SAM server clusters (Primary / Secondary / Auxiliaries)
12800 TCP Static Encryption
Encryption provided by AES
Cipher Algorithm with 128
bit Cipher Strength.
Internal system communications protocol (JBoss clustering)
During run-time operations, the 5620 SAM Auxiliary use this port
to send and receive information to and from the 5620 SAM Server.
The number of required ports depends on the number of 5620 SAM
Auxiliary workstations that are installed.
Note that 5620 SAM can be configured to use a different port for
this purpose. The procedure is available from Alcatel-Lucent
Personnel.
13528 TCP None. Listening port for CORBA notifications from 1830 OCS NEs.
This port is not used on the 5620 SAM Auxiliary.
5620 SAM Cflowd Auxiliary
21
Ports from 1023 -
65536
TCP None.
See SCP and SFTP as secure
alternatives
FTP (Passive)
This port is used to enable ftp communication between the 5620
SAM DCP Server and the 5620 SAM Server or dedicated ftp server
for retrieving IPDR files.
22 TCP Dynamic Encryption
Cipher Suite and strength as
per RFC 4253
SSH/SCP/SFTP
This port is used to enable SSH (SFTP/SCP) communication
between the 5620 SAM DCP Server and the 5620 SAM Server or
dedicated ftp server for retrieving IPDR files.
1090 TCP None. JBoss RMI/JRMP socket for connecting to the JMX MBeanServer.
Used for 5620 SAM Server to Cflowd Aux communication.
1098 TCP None. JBoss Socket Naming service used to receive RMI request from
client proxies.
Used for 5620 SAM Server to Cflowd Aux communication.
1099 TCP None. JBoss The listening socket for the Naming service.
Used for Jboss communication between 5620 SAM and Cflowd
Aux.
4444 TCP None. JBoss Socket for the legacy RMI/JRMP invoker.
Used for Jboss communication between 5620 SAM to Cflowd Aux.
4445 TCP None. JBoss Socket for the legacy Pooled invoker.
Used for Jboss communication between 5620 SAM to Cflowd Aux.
4446 TCP None. JBoss Socket for the JBoss Remoting Connected used by Unified
Invoker.
Used for Jboss communication between 5620 SAM to Cflowd Aux.
4447 TCP None. JBoss Socket for JBoss Remoting Connections.
Security Port Information
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
5620 SAM
3HE-09809-AAAG-TQZZA 13.0 R7
Issue 1 December 2015
7-11
