Table 7-9 Firewall rules for traffic coming into the 5620 SAM Server(s) from the
5620 SAM Client(s) (GUI/OSS) (continued)
Protocol From port On To port On Notes
TCP Any SAM GUI Client 80 Server(s) HTTP
TCP Any SAM-O Client 8443 Server(s) HTTPS
TCP Any SAM GUI Client 8444 Server(s) HTTPS
TCP Any SAM-O Client 8980 Server(s) HTTP
TCP Any SAM GUI Client 443 Server(s) HTTPS
TCP Any SAM-O Client 9443 Server(s) HTTPS
TCP Any SAM-O
3GPP-compliant Client
9735 Server(s) Corba
When there is a firewall configured, and there are redundant 5620 SAM Auxiliary
workstation(s), the following rules need to be applied to the appropriate interface. If
multiple interfaces are used for communication to the clients (GUI and OSS) and
auxiliary servers, the network traffic from the 5620 SAM Servers and 5620 SAM
Auxiliaries could pass through the SAM client interface (NIC 3 on
Figure 8-2,
“Distributed 5620 SAM Server/Database deployment with multiple network interfaces”
(p. 8-4)
) or the SAM network interface (NIC 1 on Figure 8-2, “Distributed 5620 SAM
Server/Database deployment with multiple network interfaces” (p. 8-4)
) on the 5620
SAM Server.
Table 7-10 Firewall rules for traffic coming into the 5620 SAM Server(s) from the
5620 SAM Auxiliary Statistics / Call Trace Server(s)
Protocol From port On To port On
TCP Any Auxiliary Server(s) 1097 Server(s)
TCP Any Auxiliary Server(s) 1099 Server(s)
TCP Any Auxiliary Server(s) 4447 Server(s)
Table 7-11 Firewall rules for traffic coming into the 5620 SAM Server(s) from the
5620 SAM Auxiliary Cflowd Server(s)
Protocol From port On To port On
TCP Any Auxiliary Server(s) 21 Server(s)
TCP Any Auxiliary Server(s) 22 Server(s)
TCP >1023 Auxiliary Server(s) >1023 Server(s)
TCP Any Auxiliary Server(s) 1099 Server(s)
TCP Any Auxiliary Server(s) 8080/8443 Server(s)
