Table 7-14 Firewall rules for setups with redundant 5620 SAM Servers.
(continued)
Protocol From port On To port On
TCP Any Servers 9010 Servers
TCP Any Servers 11800 Servers
TCP 11800 Servers Any Servers
TCP Any Servers 12010 Servers
TCP 12010 Servers Any Servers
TCP Any Servers 12300-12307 Servers
TCP 12300-12307 Servers Any Servers
TCP > 32768 Servers > 32768 Servers
When there is a firewall at the SAM management interface (NIC 1 on Figure 8-2,
“Distributed 5620 SAM Server/Database deployment with multiple network interfaces”
(p. 8-4)
) and 5620 SAM Auxiliary Statistics / Call Trace Servers are configured, then the
following rules need to be applied:
Table 7-15 Firewall rules for traffic coming into the 5620 SAM Server(s) from the
5620 SAM Auxiliary Statistics / Call Trace Server(s).
Protocol From port On To port On
TCP Any Auxiliary Server(s) 12300-12307 Server(s)
TCP 12300-12307 Auxiliary Server(s) Any Server(s)
TCP Any Auxiliary Server(s) 12800 Server(s)
TCP 12800 Auxiliary Server(s) Any Server(s)
When there is a firewall at the SAM management interface (NIC 1 on Figure 8-2,
“Distributed 5620 SAM Server/Database deployment with multiple network interfaces”
(p. 8-4)
) and NAT is configured, then the following rules need to be applied. Services
require the use of public addresses.
5620 SAM Database firewall and NAT rules
When there is a firewall at the interface that reaches the SAM management network (NIC
1on
Figure 8-2, “Distributed 5620 SAM Server/Database deployment with multiple
network interfaces” (p. 8-4)
), the following rules apply.
Security Firewall and NAT rules
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
7-22
5620 SAM
3HE-09809-AAAG-TQZZA 13.0 R7
Issue 1 December 2015
