Table 3-5 5620 SAM Virtual Machine minimum configuration with auxiliary
For networks not exceeding:
• 675 MDAs
• 1,000 GNEs
• 5 simultaneous 5620 SAM Clients (GUI or OSS)
• 1000 elemental STM tests every 10 minutes
• 50,000 performance or 100,000 accounting statistics records every 15 minutes
• 50,000 TCAs
• 2 Call Trace Sessions (if using a 5620 SAM Auxiliary Call Trace Collector)
• 10,000 Cflowd flows and 1M unique records in memory (if using a 5620 SAM Auxiliary Cflowd Collector)
5620 SAM application VM Guest H/W Resource Requirements
5620 SAM Server 3 * x86 CPU Cores, minimum 2.4GHz
16 GB RAM minimum
1 SAS 10K RPM disk drive of at least 146 GB each in size
5620 SAM Database 3 * x86 CPU Cores, minimum 2.4GHz
16 GB RAM minimum
2 SAS 10K RPM disk drives of at least 146 GB in size is required
5620 SAM Auxiliary (Statistics and/or Call
Trace)
3 * x86 CPU Cores, minimum 2.4GHz
8 GB RAM minimum
1 SAS 10K RPM disk drive of at least 146 GB in size is required
5620 SAM Auxiliary (Cflowd) 4 * x86 CPU Cores, minimum 2.4GHz
16 GB RAM minimum
1 SAS 10K RPM disk drive of at least 146 GB in size is required
All of the minimum hardware platforms above are also applicable in situations where the
5620 SAM application is installed in a redundant configuration.
