5.6 Disassembly process evaluation
We list the MK20 parts disassembly time, technique levels and disassembly methods as below, for
technique levels, Class 1 signifies easy to disassembly, Class 2 signifies normal to disassembly and Class
3 signifies hard to disassembly.
Spare part
Time for
disassembly
Jigs for
disassembly
Difficulty Class
Remark
Back Casing Assembly
6s
Plastic flake
Class 1
LED&KEY Furnished
FPC
9s
Plastic flake
Class 1
Main Antenna
5s
Tweezers
Plastic Flake
Class 1
Main PCBA
5s
Plastic Flake
Class 1
Battery Cabinet
Assembly
3s
Plastic Flake
Class 1
LI-Polymer Battery
5s
Tweezers
Class 1
SIM Card Cover Assy
4s
Tweezers
Class 1
6 Disassembly Complete
 Below table lists MK20 L2 spare parts, which is just for reference.
 NOTE: The SPL here is just for reference. Actual Spare Part List depends on the CU reference. Please
check with RSH webshop or Forlog system for the spare part list of specific CU.
