Alcoa 244 - SPECIFICATIONS; MODEL 244 TOOL SPECIFICATIONS

5
244/244OS Series Tooling Alcoa Fastening Systems
3.725
94.60
1.780
45.21
ø
.890
22.61
6.890
175.00
3.636
92.35
4.105
104.3
4.760
120.90
12.920
328.20
.945
24.00
1.890
48.00
ø
10°
• Stroke: .562 in
• Weight: 5 lbs 11oz
• Air Pressure: 90-100 psi
• Capacity: 4606 lbs @ 90 psi
• Speed/Cycles: 30 per minute
• Noise Level: 75 dBA @ 90 psi
