Alcoa 244 - MODEL 2440 S TOOL SPECIFICATIONS

6
244/244OS Series Tooling Alcoa Fastening Systems
.945
24.00
.890
22.61
4.760
120.90
12.920
328.20
4.105
103.30
ø
3.725
94.60
1.780
45.21
ø
10°
3.886
98.70
4.497
114.21
4.625
117.50
3.636
92.35
1.890
48.00
ø
• Stroke: Adjustable 0 - .500 in
• Weight: 5 lbs 11oz
• Air Pressure: 90-100 psi
• Capacity: 4606 lbs @ 90 psi
• Speed/Cycles: 30 per minute
• Noise Level: 75 dBA @ 90 psi
INCHES
MM
M
M
ODEL
ODEL
244OS T
244OS T
OOL
OOL
S
S
PECIFICA
PECIFICA
TIONS
TIONS
