3
US/CAN
Consumer safety information 2
Safety warnings 2
Intended use 3
Prohibited use 3
Technical specication 3
OPERATING INSTRUCTIONS
Activating Alde Flow 6
Operating instructions
Using Alde Flow 7
Storage and Winterizing 7
Maintaining the Alde Flow 8
Troubleshooting 8
Important information 8
Warranty Product Registration 9
Warranty Statement
INTENDED USE
These instructions explain the operation of the Alde Flow.
These instructions are approved for The Alde Flow tted
in recreational vehicles.
California Proposition 65 lists chemical substances known to the state to cause cancer, birth defects, death,
serious illness or other reproductive harm. This product may contain such substances, be their origin from fuel com-
bustion (gas) or components of the product itself.
TABLE OF CONTENTS
PROHIBITED USE
To be used in recreational vehicles and no other places.
CAUTION
OBSERVERA
ATTENTION
VOORZICHTIG
To avoid possible injury or damage to the heating
system, please read and follow instructions carefully
before using the Alde Flow.
These instructions are approved for The Alde Flow installed in Recreational Vehicles (RVs).
TECHNICAL SPECIFICATION
Model Alde Flow
Width 8.85 in / 225 mm
Length 12.6 in / 320 mm (Without pump and connections)
Height 7 in / 180 mm
Weight 5 lb / 2.3 kg (Without pump and connections)
Volume 1.6 Gallon / 6.0 Liter
Power 12VDC 0.3Amp
Max Pump Pressure domestic water: 0.22 MPa / 2.2 bar
Max radiator water pressure: 0.05 MPa / 0.5 bar
Continuous Hot Water Performance: 0.92 Gallon / 3.5 liters* per min @ T
IN
50°F (10°C), T
OUT
104°F (40°C)
*When installed with 3020 HE model year 2017 (LPG + 3kW electric)
• There may be a variation between the temperature
delivered from the boiler and the temperature at the
tap due to water conditions or the length of pipe to
the boiler.
• The presence of a ow restrictor in the hot water
line may limit the water ow.
