Troubleshooting
Problem
Possible Cause Solution
Jaws are locked in
position.
Clamping Locking lever (11) is in
the locked position.
Push up the clamp locking lever (11) to
the unlock position (Fig J), then using your
foot, push down on the clamp foot pedal
(8) to release.
Rear folding leg is
moving
Rear leg release knob (4) is not
tightened.
Tighten the rear leg release knob (4) in
a clockwise direction to fully secure into
position.
Front folding legs
are not secure.
Front leg locking knob (6) not
engaged.
Ball bearing has not engaged in
the front leg lock notch (10).
Ensure the front leg locking knob (6) is
engaged. A click can be heard when it
locks into place.
Ensure the ball bearing engages in the
front leg lock notch (10).
Sliding clamp rail
(2) will not release
from the end of the
clamping jaws.
Safety slider (3) has not not
engaged to release.
Push up the safety slider (3) to allow
release of the sliding clamp rail from the
end of the clamping jaws.
For all other issues, please contact Customer Service on 1800 909 909
or email help@powertoolsupport.com
