45W Staple / Nail Gun
AFTER SALES SUPPORT
(toll free)MODEL No.: PCT161 • 07/2019 10366
e-mail: info.aldi@positecgroup.com
AUS
12
1300 889 028
AUS
WARNING! Please read and understand this instruction
manual before use and keep it for your future reference.
Your power tool should only be passed on together with this
instruction manual.
Assembly
Warning: Switch off the machine and unplug before
inserting nails (10) and staples (9) .
To load nails (10) and staples (9) (See Fig A1-A4)
1) Turn the staple / nail gun upside down to access the magazine (7).
2) Press the lever for loading magazine (3) and pull out the state nail
guage (8) toward the rear.
3) Insert the staples (9) or nails (10) strip into magazine (7) with nails
(10) or staples (9) pointing upwards (maximum capacity 50 staples (9)
or 50 nails (10) )
NOTE: Nails (10) are to be inserted on either side of the magazine.
4) Insert the magazine (7) again until it engages.
A1
A4
A2 A3
Assembly
