MODEL: HCE2500 PRODUCT CODE: 64124 03/2019
Using the high pressure washer correctly
• The high pressure washer must be stood on a level, stable surface.
• It is recommended that you adopt the correct operating position every time you
use the high pressure washer with one hand on the gun and the other on the
lance.
• Never direct the water jet at electrical lines or the high pressure washer itself.
• Never use the high pressure washer in potentially explosive areas under any
circumstances!
• The operating temperature must be between +5 and + 50 °C.
• Do not cover or modify the lance or the spray nozzles in any way.
• The high pressure washer is designed to be used with cold or lukewarm water
(max. 50 °C); higher temperatures can damage the high pressure washer.
• Do not use water that is dirty, gritty or contains any chemical products, as these
could impair operation and shorten the life of the high pressure washer.
m Warning! Risk of explosion Do not spray ammable liquids.
m Warning! Water that has passed through the non-return valve is not drinkable.
m Warning! If cleaning agent gets into contact with your skin or into your eye,
rinse immediately with lots of clean water. Then consult a doctor or follow the steps
described on the safety data sheet or provided by the manufacturer of the cleaning
agent.
Water inlet connector (Fig. 1/2)
The quick connector (12) has a standard hose coupling system. Plug the hose cou-
pling of the supply hose (min. Ø 1/2“/13 mm) to the quick connector (12).
Always use a reinforced hose with a standard coupling for the water inlet. The hose
should be at least 6 m in length (not supplied).
A backow preventer must be installed between the drinking water and the high
pressure washer! Ask your local plumber about this.
AUS
Before operation HCE2500
