2 OVERVIEW
2.1 OVERVIEW PARENT UNIT:
1. sound indication LED’s
2. volume up; up button when
programming
3. volume down; down button when
programming
4. button MENU/OK
5. link-check (
), see below
6. loudspeaker
7. charge contacts
8. battery compartment
9. microphone
10. start/stop lullaby
11. display (see paragraph 2.3)
12. power on/off
13. talk back
1
5
4
3
2
10
12
11
8
7
13
6
9
Link check :
• fl ashes when there is no link between baby unit and parent unit or
parent unit is out of range with the baby unit.
• on steadily when linked to the baby unit
• in the full eco mode this lamp only lights when the parent unit actual
receives noise from the baby unit; in idle state this lamp is OFF
during FULL ECO mode
