2.2 PARENT UNIT:
1. photo cell for the display
brightness
2. display power button (sound
transmission remains active)
3. parent unit power button
4. push-buttons for loud or soft
volume
5. talk-back button to baby unit
6. power indicator
7. MUTE indicator, illuminates
when the volume is set to
level 0 (off)
8. display
9. to confirm changes during or
after setup and to return to
the standard display
10. built-in microphone
11. built-in speaker
12. battery cover
13. table stand
14. power adaptor input
76
1 432 5
Talk
1
2
2.3 CHARGER:
1. control light, illuminates when
the parent unit is placed onto
the charger and is being
charged (attention: this light
won’t switch off when the
battery is fully charged)
2. power adaptor input (rear)
2.4 DISPLAY IN STANDBY MODE:
1. touch to enter the night light,
lullabies and star projector menus
2. actual time
3. reception indicator:
4 bars: excellent reception
3 bars: good reception
2 bars: average reception
1 bars: weak reception
4. temperature of the room in which
the baby unit is placed, the backlighting will indicate the temperature status:
<15°C blue colour too cold
16-20°C yellow colour recommended
21-24°C orange colour too warm
>25°C red colour too hot
5. the
X
icon will appear here when the speaker is switched off (level 0); nothing
is shown here when the speaker is switched on
6. battery indicator:
battery full (battery colour is green)
battery 3/4 full (battery colour is green)
battery 1/2 full (battery colour is yellow)
battery 1/4 full (battery colour is red)
battery nearly empty (battery outline ashes in red)
battery is being charged
7. sound indicator: 4 green and 3 red bars will illuminate according to the rhythm
of the baby making sounds; this is especially useful when the volume is muted
41 2 3 5
6
7
