Alecto FR-14 - Technical Specifications

20
INTRODUCTION
The Alecto FR-14 is a PMR-446 Two-Way Radio. This two-
way
radio will allow you to communicate with each other or
with other (Alecto) two-way radios free of charge, provided
the devices conform to the PMR-446 standards.
The Alecto FR-14 devices are build conform to the essential
conditions and provisions as described in the EU directive
1999/5/EC. The statement of conformity is available on our
website at www.alecto.info
TECHNICAL SPECIFICATIONS
Operating frequency: 446.00625MHz tot
446.09375MHz
Transmitting power: 0.5Watt
Channel spacing: 12.5KHz
Battery: 4.5V (3x AAA batterij)
Range:: tot 5Km
Battery life: zenden: tot
3 uur
standby: tot
3 dagen
(gebaseerd op Alkaline batterijen
en afhankelijk van gebruik)
Weight: 111 gr. (incl. batterijen)
Dimensions: 90(140) x 50 x 30mm
Conforms to: EN 300 296-2 V1.1.1
EN 301 489-5 V1.3.1
EN 60065:2002
EN
