5
2.2 Outdoor unit:
20. Rain meter
21. Antenna
22. Wind speed meter
23. Temperature + air humidity sensor
3. INSTALLATION
Attention: after the installation, it may take several hours up to a day before the correct values
are displayed. Additionally, after replacing exhausted batteries in the indoor unit, all measured
data in the indoor unit will be erased.
3.1 Power supply:
Advice regarding batteries:
We advise you to use normal alkaline batteries of high quality for the indoor unit. Alkaline batteries with
a capacity of 2000mAh have a lifespan of over one year. Rechargeable batteries are not recommended
because of their lower supply voltage.
Also the outdoor unit is powered by 3 AA 1.5Volt batteries, but because normal Alkaline batteries
perform poorly or not at all at temperatures of around or below 0°C, it’s not recommended to use
standard Alkaline batteries for the outdoor unit.
For that reason, we advise you to use Lithium batteries for the outdoor unit that are designed to function
well within a temperature range of -20°C to 60°C. These batteries can be ordered via the service
department of Alecto via www.alecto.info
Lithium batteries with a capacity of 2900mAh have a lifespan of over one year.
26
27
Side view Bottom view
24. Wind direction vane
25. LED (transmit indicator)
26. RESET button
27. Battery compartment
25
20
21
22
24
23
